24V COB LED IP65 STRIP REEL - 5M

The xcite 24V COB LED IP65 Strip Reel 5m delivers a seamless, dot free continuous LED strip light using high density Chip on Board technology. The IP65 rated coating provides protection in moisture exposed areas, supporting reliable low voltage installation with dimmable and non dimmable drivers.

Where to Buy
  • xcite cob 5m web
  • xcite cob 5m reverse web
  • xcite cob led strip web
  • xcite cob 20m ip65 web
  • xcite cob 5m web
  • xcite cob 5m reverse web
  • xcite cob led strip web
  • xcite cob 20m ip65 web
Where to Buy
  • Suitable for under cabinet LED strip lighting in kitchens, bars and restaurants
  • Weatherproof IP65 construction
  • 875 lumens per metre
  • 7W per metre
  • Up to 125 lumens per watt efficacy
  • 416 LED chips per metre for continuous dot free uniform illumination
  • Available in warm white [3000K] or neutral white [4000K]
  • Cuttable reel every 40mm
  • 3M adhesive backing tape
  • 1m cable tails, pre soldered to strip at one end
3000K - WW4000K - NW3 Years WarrantyElectrical class 3IP65
24V COB LED IP65 STRIP REEL - 5M Installation Guide Icon

Installation Sheet
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

No
No
{"min":3000,"max":4000}
Order Code Description Data sheet Buy Now
XCSR5M65WWCOB 7 W/m - Silicon - IP65 - 3000K View
XCSR5M65NWCOB 7 W/m - Silicon - IP65 - 4000K View
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

No
No
{"min":3000,"max":4000}
Order Code Description lm/W lm/m W/m Data sheet Buy Now
XCSR5M65WWCOB 7 W/m - Silicon - IP65 - 3000K 125 875 7 View
XCSR5M65NWCOB 7 W/m - Silicon - IP65 - 4000K 125 875 7 View
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

No
No
{"min":3000,"max":4000}
Order Code Description A
(mm)		 B
(mm)		 C
(mm)		 Cut Out
(mm)		 Data sheet Buy Now
XCSR5M65WWCOB 7 W/m - Silicon - IP65 - 3000K 5000 8 2 40 View
XCSR5M65NWCOB 7 W/m - Silicon - IP65 - 4000K 5000 8 2 40 View
24V COB LED IP65 STRIP REEL - 5M Line Drawing
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

No
No
{"min":3000,"max":4000}
Order Code Description Energy Class ERP
Instructions		 EPREL Site
XCSR5M65WWCOB 7 W/m - Silicon - IP65 - 3000K Energy Class E View Visit
XCSR5M65NWCOB 7 W/m - Silicon - IP65 - 4000K Energy Class D View Visit

24V COB LED IP65 STRIP REEL - 5M Line Drawing
